Vertebral Structure Pop Quiz


Vertebral Structure Pop QuizVersion en ligne Select the correct answer. par Melissa Gauntner 1 What structure will be demonstrated of the cervical spine if the patient is rotated 45 degrees towards their right side with a 15-20 degree caudal angle? a right intervertebral foramina b right zygapophyseal joint c left intervertebral foramina d left zygapophyseal joint 2 If the patient is positioned for a right lateral cervical projection, which of the following will be clearly demonstrated? (Select all that apply) Choose one or more answers a spinous processes in profile b transverse processes c right zygapophyseal joints d pedicles e intervertebral disc spaces f articular processes 3 The lateral thoracic projection will demonstrate which of the following? a zygapophyseal joints and articular processes b zygapophyseal joints and pedicles c intervertebral foramina and articular processes d intervertebral foramina and pedicles 4 When imaging the thoracic zygapophyseal joints, how much is the patient rotated from the supine position? a 30 degrees b 45 degrees c 70 degrees d 90 degrees 5 A patient is positioned in the LPO position for an oblique projection of the lumbar spine. Which structure is demonstrated by the ear of the Scottie Dog? a right pedicle b left superior articular process c right inferior articular process d left transverse process 6 Which SI joint is demonstrated when the patient is in an anterior oblique position and the CR is centered to the level of the ASIS? Choose one or more answers a The SI joint that is depressed. b The SI joint that is elevated. c Both SI joints. 7 Which structures are being demonstrated in the image? a right spinous processes b right zygapophyseal joints c left zygapophyseal joints d left costovertebral joints 8 What structure is the letter "A" referencing? a right intervertebral foramen b left intervertebral foramen c right pedicle d left intervertebral disc space Feedback 1 The intervertebral foramina closest to the IR will be demonstrated in the anterior oblique positions (RAO and LAO) when the central ray is angled 15-20 degrees caudal. The intervertebral foramina farthest from the IR will be seen in the posterior oblique positions (LPO and RPO) when the central ray is angled 15-20 degrees cephalic. 2 Zygapophyseal joints and spinous processes will be seen in profile for the lateral cervical projections. Although superimposed, the z-joints closest to the IR will demonstrate less magnification. Because the z-joints are demonstrated, the superior and inferior articular processes are seen as well. The intervertebral disc spaces, will be demonstrated on all projections if positioned correctly. 3 When the intervertebral foramina are demonstrated, the pedicles are projected in profile as well. The lateral projection of the thoracic and lumbar spine will show the intervertebral foramina the best. 4 The zygapophyseal joints lie at a 70 degree angle from the MSP. 5 The LPO position of the lumbar spine will demonstrate the left zygapophyseal joints (z-joints closer to IR). The z-joints are comprised of the articular process articulations. In reference to the Scottie Dogs, the "ear" represents the superior articular process and because the patient is positioned in the LPO position, this is demonstrating the left superior articular process. 6 In the anterior oblique positions, the depressed SI joint will be demonstrated with the posterior oblique positions are used to evaluate the elevated SI joint. 7 The image depicts an AP oblique, RPO position, projection of the thoracic spine. The z-joints farthest (left) from the IR are best visualized. 8 (A) Right IVF (image is an LPO position) (B) Right pedicle (C) Intervertebral disc space (not defined by right or left as it is cylindrical in shape) (D) 1st rib

Vous pouvez intégrer le jeu dans un LMS compatible avec LTI 1.1 ou LTI 1.3 comme Canvas, Moodle ou Blackboard. Les scores seront ainsi automatiquement enregistrés dans le carnet de notes de la plateforme.

Vertebral Structure Pop Quiz

Test

À propos de cette activité

Créé par

Téléchargez la version pour jouer sur papier

Top Jeux

Test

Tissues - Practice Quiz

Test

Practice Quiz - Punnett Square, Variation, and Mutations

Test

Spanish Alphabet Listening

Test

Photosynthesis vs Cellular Respiration - Practice Quiz

Test

UPS 5 Seeing Habits Quiz

Vertebral Structure Pop QuizVersion en ligne

par Melissa Gauntner

What structure will be demonstrated of the cervical spine if the patient is rotated 45 degrees towards their right side with a 15-20 degree caudal angle?

If the patient is positioned for a right lateral cervical projection, which of the following will be clearly demonstrated? (Select all that apply)

Choose one or more answers

The lateral thoracic projection will demonstrate which of the following?

When imaging the thoracic zygapophyseal joints, how much is the patient rotated from the supine position?

A patient is positioned in the LPO position for an oblique projection of the lumbar spine. Which structure is demonstrated by the ear of the Scottie Dog?

Which SI joint is demonstrated when the patient is in an anterior oblique position and the CR is centered to the level of the ASIS?

Choose one or more answers

Which structures are being demonstrated in the image?

What structure is the letter "A" referencing?
